Risk of Spill Information for the Goulburn system

Thursday 15 February, 2024

An update to the deductions from spillable water accounts was made as part of the February 15 seasonal determination assessment.

The risk of spill in the Goulburn system at 15 February 2024: 60%
This value represents the percentage of years that spills occur from Lake Eildon taking into account the current storage volume, storage releases, inflows and evaporation from the storage using the historic data available.

Note: 10% or lower is the threshold for a declaration that would return water quarantined in spillable water accounts to allocation bank accounts.

Volume needed to fill Lake Eildon at 1 February 2024: 70,500 ML

Click here to find the current volumes in Goulburn system spillable water accounts.

Ranked historic inflow to Lake Eildon: Nov - Jan

Ranked historic inflow to Lake Eildon

Ranked historic inflow to Lake Eildon: Nov – Jan 2024. Inflow for the Nov– Jan period is indicated by the red line: 222,265 ML

Description and Tabulation of the graphical content inflow to Lake Eildon: Nov-Jan

A bar graph titled Ranked historic inflow to Lake Eildon: Nov - Jan 2024 is on the page above. X axis label “% Probability of Exceedance” which spans 99% on the left to 1% on the right. Y axis label is “3 month inflow – units megalitres (ML)”. Significant highlighted data in the graph is the inflow for the Nov - Jan 2024 period is indicated by the red line: 222,265 ML.

Each % probability of exceedance is reported from 99% to 1%. Inflow values of greater than 80,000 megalitres have a high probability of occurrence, i.e. > 90%. There is less than 10% probability of inflows above 400,000 megalitres.

Tabulation of data from the image above of the graph

% probability of exceedance 3 month inflow in megalitres
99% 6,220
90% 80,626
80% 101,518
70% 124,824
60% 149,228
50% 165,390
40% 197,878
2023/24 222,265
30% 238,244
20% 288,885
10% 399,311
1% 855,951



Ranked historic inflow to Lake Eildon: February - June

Ranked historic inflow to Lake Eildon

Ranked historic inflow to Lake Eildon: February – June. The difference between the full supply volume of Lake Eildon and the volume at 1 February 2024 is shown by the green line: 70,500 ML.

Description and Tabulation of the graphical content inflow to Lake Eildon: February - June

A bar graph titled Ranked historic inflow to Lake Eildon: February– June is on the page above. X axis label “% Probability of Exceedance” which spans 99% on the left to 1% on the right. Y axis label is “3 month inflow – units megalitres (ML)”. Significant highlighted data in the graph is the difference between the full supply volume of Lake Eildon and the volume at 1 February 2024 is indicated by the green line: 70,500 ML.

Each % probability of exceedance is reported from 99% to 1%. Inflow values of greater than 80,000 megalitres have a high probability of occurrence, i.e. > 90%. There is less than 10% probability of inflows above 550,000 megalitres.

Tabulation of data from the image above of the graph

% probability of exceedance 5 month inflow in megalitres
99% 64,270
Current airspace 70,500
90% 85,915
80% 110,765
70% 122,709
60% 144,353
50% 191,500
40% 234,368
30% 269,138
20% 374,314
10% 548,481
1% 1,1274,319



Notes for charts:

There are 132 years of historic inflow data available for Lake Eildon (inflow data for the period before the construction of the dam are based on modelled inflows). The first chart displays the volume of inflow to Lake Eildon for the period 1 November to 31 January in each of those 132 years. The volumes of inflow shown are ranked in order from lowest to highest with the red line representing the volume of inflow recorded for the period in the current year (2023/24).

The second chart displays the volume of inflow to Lake Eildon for the period 1 February to 30 June in each of the 131 years of historic data. The volumes of inflow shown are ranked in order from lowest to highest. The volume difference at Lake Eildon between full supply and the storage volume on 1 February is indicated by the green line.

Probability of exceedance: Probability that the volume of inflow will be equal to or greater than a specified volume in any given year. For example, in the first chart above, the probability that inflows to Lake Eildon from 1 February to 30 June will be greater than 200,000 ML in any given year is ~50%.

Additional notes:

  • The volumes in spillable water accounts can change due to seasonal determination increases, provided there has been no low risk of spill declaration made
  • Operation to target filling arrangements at Lake Eildon could see reductions to spillable water accounts prior to the storage reaching the full supply level.
  • Current year inflows are based on operational data.
